How To: Back seat delete - side panel plugs

Post by Wing on Mon 14 Mar 2011, 3:17 pm

I removed my entire back seat some time ago and in place of it - installed standard black auto carpet from the local auto store. Then after awhile got tired of seeing the holes left behind from where the back portion of the seat was mounted.

What you'll need:

(2) Honda # 83736-S30-000ZA (these are the exact same plugs meant for your rear strut access)
^ These plugs only cost me around $5 each
razer blade
sharpie


Step 1: Remove both interior quarter panels.
Step 2: Install plugs as far as they will slide on the round portion of the hole and mark where it starts to angle.
Step 3: Carefully cut out your marks (this rubber is very thin and you can go through it eaisly)
Step 4: Smooth out the bottom best you can - this part will be sitting on the outside and you don't want it to bow
Step 5: Install plugs, re-install panels, and there you have it! No more eyesore!

I wont have my interior back together for another week or so, in the middle of a few more things. So I'll update this with installed pictures when that's all done Smile










Wing
Been around a bit
Been around a bit

Posts : 535
Join date : 2011-01-26
Age : 28
Location : DelaWHERE?

Back to top Go down

Re: How To: Back seat delete - side panel plugs

Post by Wing on Fri 15 Apr 2011, 11:10 pm

I don't understand why ever photo I post gets cut off halfway...

Wing
Been around a bit
Been around a bit

Posts : 535
Join date : 2011-01-26
Age : 28
Location : DelaWHERE?

Back to top Go down

Re: How To: Back seat delete - side panel plugs

Post by xxfallacyxx on Wed 04 May 2011, 11:02 am

It's a forum thing... I'll ask tech about it later. BTW will be adding your write-ups to the sticky thread. Good work. Smile
